HTF-001 Martindale Abrasion And Pilling Tester (2,4,6,8 heads-Touch Screen Control)

Martindale Abrasion & Pilling Tester used to determine the abrasion and pilling resistance of all kinds of textile structures.Samples are rubbed against known abradents at low pressures and in continuously changing directions and the amount of abrasion or pilling is compared against standard parameters. .

The tester is equipped with electronic preset batch counter, timer and pooled sample clips and load device (compatible with international testing standards)

HTF-001 Martindale Abrasion And Pilling Tester (2,4,6,8 heads-Touch Screen Control)

Main technical parameters:

Testing Head: 2 heads

Display: LED

Accumulate count: 1~999999

Dimensions (L x W x H) 560×640×370mm

Power supply AC380V, 180W or AC220V, 180W

Pressurized material weight:

(a) wear resistance test: clamps component 200 ± 1g, cloth sample hammer 395 ± 2g , furniture decorations specimen hammer 594 ± 2g.

(b) pilling test: gripper assembly 155 ± 1g, heavy punch 260 ± 1g

Relative velocity 50 r / min

Effective friction diameter:

(a) wear resistance test: φ28.8mm (b) pilling performance test: φ90mm

HTF-001 Martindale Abrasion And Pilling Tester (2,4,6,8 heads-Touch Screen Control)

Standard: EN ISO 20344 6.12 Determination of abrasion resistance of lining and insock

BS 3424/5690,IWTO 40-88,BS EN 388/530,IWSTM 112/196,ASTM 4966/4970 IS 12673, JIS L1096, SFS 4328, PR EN ISO 12947-1, PR EN ISO 12945-2, SATRA TM31

Dongguan Hust Tony instruments Co., Ltd ( Tony International(HK)Co., Ltd. ) has been manufacturing and developing testing machines for more than 15 years.

Our Main products are Furniture Testing Instrument, Toys Testing Equipment,Textile Testing Instrument, Leather shoes Test Equipment, Universal Testing instruments, Continue its advanced design technology and concept, excellent technology of producing and outstanding system of quality management, Tony Instruments has achieved good repute in the fields of textile testing equipments, toy testing equipments, furniture testing and other measurement test equipments. Our long-term partners include the world's two largest inspection companies SGS and TUV.

We produce equipments in line with international market testing standards, meanwhile, we provide customers with complete solutions for laboratory testing.

- Design program for laboratory

- Provision of all testing machines and consumables

- Installation and training

- Maintenance plan service

- Professional calibration and measure services

Some of our important customers, include:

SGS in France, SGS in Vietnam, SGS in China, SGS in Korea, Intertek in China, SAT in China, BACL in Shenzhen, NSF in Shanghai, ITS, BV, TUV and etc.

Sincerely administration make Tony sales network extend all over the world. Up to day Tony products spread to countrywide users. In overseas, we have customers from Vietnam, Thailand, Indonesia, Europe, Iran, Pakistan, USA, Canada, Mexico, Argentina and etc.

Our Testing machines are widely used in Textile, Toys, Furniture, packaging, footwear, leather products, environment, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields.
